Component 3, Component 4
Support the following formats and resolutions:
 Component Video YPbPr; 480i, 576i
 RGBS (RGB with composite sync); 480i, 576i
 2 x Composite (CVBS) Video and1xS-Video; 480i, 576i
AUDIO INPUT TERMINALS
Digital
Optical
Coaxial 1; Coaxial 2; Coaxial 3
Analog
Stereo Audio 1; Stereo Audio 2; Stereo Audio 3
VIDEO OUTPUT TERMINALS
Your display device(s) should be connected to these terminals. Leadshow 3G offers the following
connection configurations:
Digital
HDMI 1; HDMI 2 (both HDCP and embedded digital audio)
The HDMI (High Definition Multimedia Interface) provides the best quality video and audio output
from Leadshow 3G . If you are connecting to a display device that has a HDMI terminal, this is the
recommended option to use. This allows direct transmission of the video information from
Leadshow 3G to the display without any conversion from digital to analogue signals. Always use
high quality HDMI cables, especially for longer cable runs.
Supported output resolutions:
480p, 576p, 720p, 1080i, 640x480, 800x600, 852x480, 1024x576,1024x768, 1024x1024
ALiS, 1280x720, 1280x768, 1280x1024,1360x768, 1360x1024, 1366x768, 1368x768,
1400x788, 1400x1050,1920x1080, and customized resolutions up to 150MHz
Analog
BNC 1; BNC 2; BNC 3; BNC 4; BNC 5
Can be used either as:
 RGBHV
 RGBS (RGB with composite sync)
Supported RGBHV/RGBS output resolutions:
480p, 576p, 720p, 1080i, 640x480, 800x600, 852x480, 1024x576, 1024x768,
1024x1024 ALiS, 1280x720, 1280x768, 1280x1024, 1360x768, 1360x1024,
1366x768,1368x768, 1400x788, 1400x1050, 1920x1080, and customized
resolutions up to 165MHz
 Component Video YPbPr; 480p, 576p, 720p, 1080i
AUDIO OUTPUT TERMINALS
Digital
Optical
Coaxial
Analog
Stereo Audio 1
