7.10 PICTURE IN PICTURE/PICTURE BY PICTURE
 When Leadshow 3G is in “Picture In Picture” (PIP) mode, there is a small sub-picture on top of
the main picture, which comes from another video input source. In PIP mode, you can:
 Adjust the position of the sub-picture
 Adjust the size of the sub-picture
 Adjust the transparency of the sub-picture
 Crop the 4 sides of the sub-picture
 When Leadshow 3G is in “Picture By Picture” (PBP) mode, main picture is shifted to one side and
a sub-picture, which comes from another video input source, appears in the other side (they
are side by side). In PBP mode, you can:
 Adjust the position of the line splitting the main picture and sub-picture
 Adjust the position of the sub-picture
 Adjust the size of the sub-picture
 Crop the 4 sides of the sub-picture
 You can choose to have a frame on the sub-picture and/or main picture
 Main picture and sub-picture can be swapped
 When main picture is in passthru mode, PBP mode will be ignored
 Video Input:
 You can select any of the video input sources as the sub-picture, but with the following
exceptions:
 Audio Input:
 The audio mapped to the video source of sub-picture is the same as defined in Audio
Input Select (see Section 5.4.1). However, in a simlar way to video input, there are
exceptions:
When audio input of Audio input of
main picture is sub-picture can not be
HDMI 1 HDMI 2
HDMI 2 HDMI 1
HDMI 3 HDMI 4
HDMI 4 HDMI 3
Analog audio 1 Analog audio 2, nor Analog audio 3
Analog audio 2 Analog audio 1, nor Analog audio 3
Analog audio 3 Analog audio 1, nor Analog audio 2
When video source Video source of
of main picture is sub-picture can not be
2IMDH1IMDH
1IMDH2IMDH
4IMDH3IMDH
3IMDH4IMDH
Component 1 Component 2
Component 3 Component 4
