5.5.2 FRONT PANEL

This option controls the behavior of the Leadshow 3G LCD front panel, including:

 Back light of the LCD front panel

 Front Panel LED lights

For the LCD panel backlighting, the Active setting means auto dim after a preset period of

time. The backlight will turn on automatically when either the front panel or remote control

buttons are used

5.5.3 PASSTHRU

This option controls whether the input video should be processed by Leadshow 3G or passed thru

directly to the output port without any processing.

 Passthru from SDI and analog input is only available in firmware version 2.00 or later

 Passthru to Analog output is only available in firmware version 2.00 or later

When the checkbox is checked, the input video from the associated port is passed directly

to the output port without processing
