Installation
43300855170_002_C8 - 08/2021 - © Leybold
3.10 Connect a vacuum gauge head (only for TURBOVAC iX)
One of the listed vacuum gauge heads may be connected to connection
X101.
Connect the vacuum gauge head only after having switched off the pump
first.
Vacuum gauge head Connection
cable
Pressure range
TTR 101, TTR101 S2,
TTR 101 N, TTR 101 N(S2)
Type F 5 x 10
-4
…1500 mbar
ITR 200 S, ITR200 SL,
ITR 200 SP, ITR200 SD
Type C 5 x 10
-10
…1000 mbar
CTR 100/101,
CTR 100 N, CTR 101 N
Type C
1 x 10
-1
…1000 torr to
1 x 10
-5
…0,1 torr
TTR 91, TTR91S,
TTR 96 S, TTR 91 N,
TTR 91 N(S), TTR 96 N(S)
Type F 5 x 10
-4
…1000 mbar
PTR 90, PTR 90 N Type F 5 x 10
-9
…1000 mbar
ITR 90, ITR 90 P Type C 5 x 10
-10
…1000 mbar
The type of connected vacuum gauge head is detected automatically.
The measured value can be read out in millibar, Torr and Pascal through
parameter as real value.
P616: measured value in millibar
P617: measured value in Torr
P618: measured value in Pascal
Further parameters (like filter time, CTR vacuum gauge head subtype, gas
type correction factor etc., for example) may be set up for the respective vac-
uum gauge head.
For this refer to the interface Operating Instructions.
