102
CONFIGURATION
Indoor PCB
General Information
OFF is selected
ON is selected
OFF
ON
SW2
1 2 3 4 5 6 7 8
OFF
ON
SW1
1 2 3 4 5 6 7 8
1234567 8
1234567 8
CONFIGURATION
As is designed to satisfy various installation environment, it is important to set up
system correctly. If not configured correctly, improper operation or degrade of performance can
be expected.
DIP Switch Setting
CAUTION
!
Turn off electric power supply before setting DIP switch
• Whenever adjusting DIP switch, turn off electric power supply to avoid electric shock.
