58
WATER PIPING
Procedures about water piping and electric wiring at the indoor unit are described in this chapter.
Water piping and water circuit connection, water charging, pipe insulations will be shown for
water piping procedures. For wiring, terminal block connection, connecting with the outdoor
unit, electric heater wiring will be introduced.
Accessories connection, such as sanitary water tank, thermostat, 3way or 2way valves, etc will
be dealt in separated chapter.
Water Piping and Water Circuit Connection
Definition of terms are as follow :
- Water piping : Installing pipes where water is flowing inside the pipe.
- Water circuit connecting : Making connection between the product and water pipes or between
pipes and pipes. Connecting valves or elbows are, for example, in this category.
All connections should be complied with presented diagram.
While installing water pipes, followings should be considered :
- While inserting or putting water pipes, close the end of the pipe with pipe cap to avoid dust
entering.
- When cutting or welding the pipe, always be careful that inner section of the pipe should not be
defective. For example, no weldments or no burrs are found inside the pipe.
- Drain piping should be provided in case of water discharge by operation of the safety valve,
drain from condensate, and snow or rain. This situation can be happened when the internal
pressure is over 3.0 bar and water inside the indoor unit will be discharged to drain hose.
- In a cold climate region, water drainage must be frost-proof.
CAUTION
!
General Considerations
Followings are should be considered before beginning water circuit connection.
- Service space should be secured.
- Water pipes and connections should be cleaned using water.
- Space for installing external water pump should be provided if internal water pump capacity is
not enough for installation field.
- Never connect electric power while proceeding water charging.
WATER PIPING
