163
INSTALLER SETTING
ENGLISH
Connectivity - Energy state
The sub menu 'Energy state' can be used to influence the heat pumps's operation based on
availability of renewable energy - for instance from PV-panels.
There are two options to make use of this logic:
- Use Modbus: LG Energy Storage System (ESS) or another third-party device is connected by
Modbus serial line.
- Use Digital inputs: A third-party controller (e.g. SmartHome controller or PV inverter) is
connected through 230 V inputs ("SG-Ready contacts").
Using Modbus RTU allows to use eight different energy states, while Digital inputs provides four
different energy states.
NOTE
Use setting ‘Digital inputs assignment’ to replace Energy state 3 and/or 4 with any of Energy
states 3~8.
Digital inputs (TB_SG)
Energy state Mode Default Range
ES1 ES2
Close Open 1
Heating Off Fixed
Cooling Off Fixed
DHW Off Fixed
Open Open 2
Heating Normal Fixed
Cooling Normal Fixed
DHW Normal Fixed
Open Close 3
Heating 2 Fixed
Cooling +/- 0 Fixed
DHW 5 Fixed
Close Close 4
Heating +/- 0 Fixed
Cooling +/- 0 Fixed
DHW Target: 80°C Fixed
--5
Heating 5 0 ~ +30
Cooling -5 -30 ~ 0
DHW 30 0 ~ +50
--6
Heating 2 0 ~ +30
Cooling -2 -30 ~ 0
DHW 10 0 ~ +50
--7
Heating -2 -30 ~ 0
Cooling 2 0 ~ +30
DHW +/- 0 -50 ~ 0
--8
Heating -5 -30 ~ 0
Cooling 5 0 ~ +30
DHW +/- 0 -50 ~ 0
