LG HN1639HC NK0 Installation Manual

ANNEX
174
ANNEX
Indoor Temp.(°C)
Resistance(kΩ)
Voltage(V)
-10 °C
60 kΩ
4.1 V
-5 °C
44 kΩ
3.9 V
0 °C
33 kΩ
3.6 V
5 °C
25 kΩ
3.4 V
10 °C
0 kΩ
3.1 V
15 °C
15 kΩ
2.8 V
20 °C
12 kΩ
2.5 V
25 °C
10 kΩ
2.2 V
30 °C
8 kΩ
1.9 V
35 °C
6 kΩ
1.6 V
40 °C
5 kΩ
1.5 V
45 °C
4 kΩ
1.3 V
Indoor Temp.(°C)
Resistance(kΩ)
Voltage(V)
-10 °C
29 kΩ
4.1 V
-5 °C
22 kΩ
3.9 V
0 °C
17 kΩ
3.6 V
5 °C
13 kΩ
3.3 V
10 °C
10 kΩ
3 V
15 °C
8 kΩ
2.8 V
20 °C
6 kΩ
2.5 V
25 °C
5 kΩ
2.2 V
30 °C
4 kΩ
1.9 V
35 °C
3.2 kΩ
1.7 V
40 °C
2.6 kΩ
1.5 V
45 °C
2.1 kΩ
1.2 V
50 °C
1.7 kΩ
1 V
55 °C
1.4 kΩ
0.9 V
60 °C
1.2 kΩ
0.8 V
65 °C
1 kΩ
0.7 V
NOTE
The sensor resistance value and the voltage value at both ends may vary depending on the
ambient temperature and the value has a deviation of 5 %.
There may be some errors depending on the measurement equipment.
Room air temperature sensors (NTC 10kOhm)
Pipe temperature sensors (NTC 5 kOhm)
