INSTALLER SETTING
ENGLISH
Installer setting
• You can set the product user functions.
• Some functions may not be displayed/operated in some product types.
Menu hierarchy & Setting Explanation
Detailed
explanation
Available Setting
options (range)
Unit Default
CONFIGURATION
Control method
The product can be operated according to air
temperature, water temperature, or both.
- Water: The product operates by comparing
the current water temperature and the
target water temperature.
- Air : The product operates by comparing the
current air temperature and the target air
temperature.
- Air+Water : The product operates considering
both the water temperature and
air temperature conditions above.
O
Air / Water /
Air+Water
- Water
Select room
devices
RMC linked to
Definition to which circuit this Remote
controller is linked to.
- Circuit 1&2 : This RMC is used to control the
whole heating system
- Circuit 1: This RMC is used to control Circuit 1
(unmixed circuit) only
- Circuit 2: This RMC is used to control Circuit 2
(mixed circuit) only
O
Circuit1&2 /
Circuit1 /
Circuit2
-
Circuit
1&2
Circuit 1
Digital input
With this setting, a Digital input (Dry contact,
3rd party thermostat or external input) can be
linked to Circuit 1.
Consequently, the signal will be used as
thermo-on/off command for Circuit 1 only.
CN-CC /
CN-THMO /
CN-EXT
- CN-CC
Room air sensor
option
In case of Air- or Water+Air-control method,
either a Room sensor or the Remote controller
can be used to sense the Room air temp.
The device must be installed in a Reference
room of Circuit 1.
Room Sensor /
Remote Controller
-
Remote
Controller
