88
ACCESSORIES INSTALLATION
DN25
3 WAY
VALVE (A)
To space heating
From space heating
MAGNETIC FILTER
(RECOMMENDED)
DN25
TB1 12 / 13 / 14
CN_TH4
TB1 5 / 6
TB_SENSOR_SOLAR
SOLAR
PUMP
PT1000 (3rd-party)
SOLAR TEMP.
SENSOR
SOLAR THERMAL COLLECTOR
DHW TANK
DHW TANK
SENSOR (A)
DHW TANK
BOTTOM
SENSOR (B)
HOT
WATER
CITY WATER
SUPPLY
THERMOSTATIC
MIXING VALVE
(MANDATORY)
THERMA
V
SERVICE
SERVICE
VALVE
VALVE
SERVICE
VALVE
* Water In / Water Out installation scene may vary depending on the model.
Insert sensor until the cable tie as shown below.
CAUTION
!
Sensor mounting
Insert sensor into sensor socket and bolt it tightly.
