Liebert Mini-Mate2 MMD24E User Manual

Product Number Nomenclature
3Liebert
®
Mini-Mate2
™
PRODUCT NUMBER NOMENCLATURE
Figure 1 Model number nomenclature—Evaporator units
Figure 2 Model number nomenclature—Air-cooled, indoor condensing units
MM
D = Disconnect Switch
0 = No Disconnect Switch
MM = Liebert Mini-Mate2
Refrigerant
7 = R-407C
D36 7 A H A
Blower Type
D = Direct Drive
Internal Blower
B = Belt Drive
External Blower
Supply Power
P = 208/230V - 1 ph - 60Hz
X = 277V - 1 ph - 60Hz
S = 220V - 1 ph - 50Hz (3-ton only)
A = 460V - 3 ph - 60Hz (3-ton only)
Y = 208/230V - 3 ph - 60Hz (3-ton only)
M = 380/415V - 3ph - 50Hz (3-ton only)
E
Unit Type
E = Split Evaporator
K = Split Evaporator with Free-Cooling
ED
Humidification
H = Canister Humidifier
0 = No Humidifier
R = Remote Humidifier Contact
J = Canister Humidifier and Remote
Humidifier Contact
Reheat Type
0 = No Reheat
E = Electric Reheat
S = SCR Reheat (not available
with free-cooling)
Sensor Packages
0 = None
A = Filter Clog
B = Smoke Sensor
C = High-Temperature Sensor
D = Filter Clog & Smoke Sensor
E = Filter Clog & High-Temperature Sensor
F = Smoke Sensor & High-Temperature Sensor
G = Filter Clog, Smoke Sensor & High-Temperature Sensor
Nominal Capacity
MC
D = Disconnect Switch
0 = No Disconnect Switch
MC = Liebert Mini-Mate2 indoor condensing units
Refrigerant
7 = R-407C
H = Hot Gas
Bypass
D36 L A H 7
Head Pressure Controls
L = Liebert Lee-Temp
™
Receiver
Supply Power
P = 208/230V - 1 ph - 60Hz
X = 277V - 1 ph - 60Hz
S = 220V - 1 ph - 50Hz (3-ton only)
A = 460V - 3 ph - 60Hz (3-ton only)
Y = 208/230V - 3 ph - 60Hz (3-ton only)
M = 380/415V - 3ph - 50Hz (3-ton only)
A
Cooling Method
A = Air-Cooled
Nominal Capacity
24 = 2-ton, 60Hz
35 = 3-ton, 50Hz
36 = 3-ton, 60Hz

Liebert Mini-Mate2 MMD24E Specifications

General

Brand	Liebert
Model	Mini-Mate2 MMD24E
Category	Air Conditioner
Language	English
