Liebert Mini-Mate2 MMD24E User Manual

Site Preparation and Installation
25 Liebert
®
Mini-Mate2
™
Figure 14 Dimensions, evaporator units with optional belt drive blower assembly
Table 16 Net weight, high static blower module
Unit
Net Weight
lb (kg)
High Static
Blower Module
85 (39)
Source: DPN000194, Rev. 3
DPN000194
Rev. 3
19" (483mm)
Blower Box
Dimension
4-29/32" (125mm)
Cabinet to Cabinet
4-29/32" (125mm)
Threaded Rod
To Threaded Rod
57-13/16" (1468mm)
Overall Dimension
55-13/16" (1418mm)
Threaded Rod Centers
54" (1372mm)
Cabinet Dimension
High Static
Blower
Module
Evap
Unit
30" (762mm)
Blower Box
Dimension
5-7/8"
(149mm)
29-7/8" (759mm)
Threaded
Rod Centers
3-7/32"
(82mm)
Base to
Base
14"
(356mm)
Outlet
Dimension
6-7/8" (175mm)
6-5/16" (160mm) Outlet
9-3/4" Outlet
(248mm)
16-13/16" (427mm)
Threaded Rod Centers
24" (610mm)
Cabinet
Dimension
30" (762mm)
Cabinet
Dimension
18 "
(457mm)
Outlet
Dimension
