Liebert Mini-Mate2 MMD24E - Condensing Unit Model Codes

Product Number Nomenclature
Liebert
®
Mini-Mate2
™
4
Figure 3 Model number nomenclature—Outdoor air-cooled prop fan condensing units
Figure 4 Model number nomenclature—Water/glycol-cooled condensing units
PFH
Nominal Capacity, kBtuh
PF = Prop Fan Condensing Unit with Hot Gas Bypass
P = 208/230V - 1ph - 60Hz
Y = 208/230V - 3ph - 60Hz (3-ton only)
A = 460V - 3ph - 60Hz (3-ton only)
B = 575V - 3ph - 60Hz (3-ton only)
S = 220V - 1ph - 50Hz (3-ton only)
M = 380/415V - 3ph - 50Hz (3-ton only)
037A PL7
L = 95°F Ambient,
Liebert Lee-Temp
™
H = 105°F High Ambient,
Liebert Lee-Temp
0 = Std. Sound Level
Z = Quiet-Line
— = Standard Coil
C = Coated Coil
Cooling Method
A = Air-Cooled
Refrigerant
7 = R-407C
—
MC
D = Disconnect Switch
0 = No Disconnect Switch
MC = Liebert Mini-Mate2
indoor condensing
units
Refrigerant
7 = R-407C
H = Hot Gas Bypass
D38 2AH7
Head Pressure Controls
2 = 2-Way Standard Pressure Water Reg Valve
3 = 3-Way Standard Pressure Water Reg Valve
D = 2-Way High-Pressure Water Reg Valve
T = 3-Way High-Pressure Water Reg Valve
Supply Power
P = 208/230V - 1 ph - 60Hz
X = 277V - 1ph - 60Hz
S = 220V - 1ph - 50Hz (3-ton only)
A = 460V - 3ph - 60Hz (3-ton only)
Y = 208/230V - 3ph - 60Hz (3-ton only)
M = 380/415V – 3ph-50Hz (3-ton only)
W
Cooling Method
W = Water/Glycol
Nominal Capacity
26 = 2-ton, 60Hz
37 = 3-ton, 50Hz
38 = 3-ton, 60Hz
