Liebert Mini-Mate2 MMD24E User Manual

Site Preparation and Installation
39 Liebert
®
Mini-Mate2
™
Figure 23 General arrangement, water/glycol split systems
*
*
DPN000190
REV 1
Tube in Tube
Condenser
Tube in Tube
Condenser
High Pressure
Scroll Switch
Scroll
Compressor
Suction Line Male Quick
Connect Coupling
Liquid Line
Male Quick
Connect
Coupling
Water/Glycol
Return Line
Water/Glycol
Supply Line
Fluid Supply
To Unit
Fluid Supply
To Unit
Shutoff **
Valves
Hose Bibs **
2 - Way Water
Regulating Valve
Fluid
Return
From Unit
Fluid Return
From Unit
3 - Way Water
Regulating Valve
(Optional)
Suction Line Female Quick
Connect Coupling
Liquid Line
Female Quick
Connect
Coupling
Sensing Bulb
Service Access
Ports
Filter
Drier
Evaporator Coil
Expansion
Valve
FIELD PIPING
FACTORY PIPING
* Use Liebert sweat adapter kit with field
hard piping or use Liebert pre-charged line
set. Close-coupling option available with
MCD.
** Components are not supplied by Liebert
but are recommended for proper circuit
operation and maintenance.
External Equalizer
Hot Gas
Bypass
Solenoid
Valve
Hot Gas Bypass
Control Valve
Liquid Injection
Valve Bulb
Liquid Injection
Valve
