Product Number Nomenclature
5Liebert
®
Mini-Mate2
Figure 5 Model number nomenclature—Chilled water units
MM
D = Disconnect Switch
0 = No Disconnect Switch
MM = Liebert Mini-Mate2
Blower Type
D = Direct Drive Internal Blower
B = Belt Drive External Blower
Reheat Type
0 = No Reheat
E = Electric Reheat
H = Hot Water Reheat
D40 3AHEC
Cooling Method
C = Chilled Water
Nominal Capacity
39 = 3-ton, 50Hz
40 = 3-ton, 60Hz
AD
Valve Type
2 = 2-Way Chilled Water Valve
3 = 3-Way Chilled Water Valve
Supply Power
P = 208/230V - 1 ph - 60Hz
X = 277V - 1ph - 60Hz
S = 220V - 1ph - 50Hz
A = 460V - 3ph - 60Hz
Y = 208/230V - 3ph - 60Hz
M = 380/415V – 3ph-50Hz
Humidification
H = Canister Humidifier
0 = No Humidifier
R = Remote Humidifier Contact
J = Canister Humidifier and Remote
Humidifier Contact
Sensor Packages
0 = None
A = Filter Clog
B = Smoke Sensor
C = High-Temperature Sensor
D = Filter Clog & Smoke Sensor
E = Filter Clog & High-Temperature
Sensor
F = Smoke Sensor & High
Temperature Sensor
G = Filter Clog, Smoke Sensor & High-
Temperature Sensor
