Liebert Mini-Mate2 MMD24E User Manual

Site Preparation and Installation
Liebert
®
Mini-Mate2
™
32
Figure 18 Indoor air-cooled centrifugal condenser dimensions and pipe connections
Table 18 Centrifugal condenser dimensions, weights
ModelABCD
Net Weight
lb (kg)
MC*24A
1-7/16 (37) 11-7/16 (290) 1/2 (13) 20-7/16 (519)
230 (104)
MC*35A
240 (109)
MC*36A
Source: DPN000206, Rev. 1
50-1/4" (1276mm)
Overall Dimension
46-1/2" (1181mm)
Cabinet Dimension
48- 1/4" (1225mm)
Threaded Rod Centers
21-1/2 " (546mm)
Cabinet Dimension
19-1/2" (495mm)
Threaded Rod
Centers
Rods
for Module Support
from Ceiling (typ. 4)
C
D
Air Outlet
Duct Connection
B
A
Air Ou
tlet
Duct Dimension
Duct Flange
2-1/4"
(57mm)
1"
(25.4mm)
20-7/16"
(519mm)
Coil Inlet
Duct Conn.
Minimum Clearance 33" (838mm)
This End for Component Access
and Removal
20-3/4"
(527mm)
1/2" (13mm)
7/8" (22.2mm) Dia.
Electrical Entrance
for Low Voltage
Connection.
Suction Line
Liquid Line
Male Quick
Connect
Male
Quick Connect
Note:
Unit is evenly spaced in
reference to threaded rod centers.
DIMENSIONAL DATA
Blower Motor Service Access
Panel on Bottom of Unit
Minimum Clearance 33" (838mm)
for Component Access and Removal.
30-1/8"
(765
mm)
Coil Inlet
Duct Connection
Integral
Hanging
Bracket
Holes for Module
Rigging (typ. 2 each end)
22-1/2"
(572mm)
Cabinet
Dimension
7/8"
(22.2mm) Dia.
Electrical Entrance
for Line Voltage
Connection.
Customer Supplied
Threaded
22-3/4" (578mm)
Overall Dimension
DPN000206
Rev. 1
