Site Preparation and Installation
Liebert
®
Mini-Mate2
™
16
5.2 Ceiling Unit Weights
5.3 Equipment Inspection—Upon Receipt
When the unit arrives, do not uncrate equipment until it is close to its final location. All required
assemblies are banded and shipped in corrugated containers. If you discover any damage when you
uncrate the unit, report it to the shipper immediately. If you later find any concealed damaged, report
it to the shipper and to your Liebert supplier.
5.4 Packaging Material
All material used to package this unit is recyclable. Save it for future use or dispose of the material
appropriately.
5.5 Installing the Ceiling Units
The evaporator unit and condensing unit are usually mounted above the ceiling and must be securely
mounted to the roof structure. The ceiling and ceiling supports of existing buildings may require
reinforcements. Be sure to follow all applicable national and local codes. Use field-supplied threaded
suspension rods and 3/8-16 factory hardware kit.
Recommended clearance between ceiling grids and building structural members is unit height plus
3 in (76mm).
Install the four field-supplied rods by suspending them from suitable building structural members.
Locate the rods so that they will align with the four mounting holes in the flanges that are part of the
unit base.
Table 6 Ceiling unit weights
Model #
Weight
lb (kg)
Cooling Units *
MMD24E 225 (102)
MMD35E 225 (102)
MMD36E 225 (102)
MMD39C 230 (104)
MMD40C 230 (104)
Indoor Condensing Units
MCD24A 270 (125)
MCD35A 280 (130)
MCD36A 280 (130)
MCD26W 190 (90)
MCD37W 200 (95)
MCD38W 200 (95)
MCD38W 200 (95)
* Add 20 lb. (9kg) to units with free-cooling or hot water reheat coils.
WARNING
Risk of ceiling collapse and heavy unit falling. Can cause building and equipment damage,
serious injury or death.
Verify that the supporting roof structure is capable of supporting the weight of the unit(s) and
the accessories. (see 5.2 - Ceiling Unit Weights.)
Be sure to securely anchor the top ends of the suspension rods. Make sure all nuts are tight.
