Liebert Mini-Mate2 MMD24E User Manual

Site Preparation and Installation
13 Liebert
®
Mini-Mate2
™
5.0 SITE PREPARATION AND INSTALLATION
5.1 Installation Considerations
The evaporator unit is usually mounted above the suspended ceiling of the space to be conditioned.
Ducted systems may be installed in a different room.
5.1.1 System Configurations
The typical system configuration has a separate evaporator or cooling unit and a condensing unit.
Chilled water systems are self-contained units. Refer to Tables 1 and 2 and to Figures 8, 9 and 10
for different system combinations and unit configurations that are possible.
NOTE
Before installing unit, determine whether any building alterations are required to run piping,
wiring and ductwork. Carefully follow all unit dimensional drawings and refer to the
submittal engineering dimensional drawings of individual units for proper clearances.
Table 1 System configurations - 60Hz
Nominal
Capacity
Cooling
Unit
Condensing Unit
Indoor Air-Cooled
Centrifugal fan
Outdoor Air-Cooled
Propeller Fan
Indoor
Water/Glycol
2 Tons MM_24E MC_24A PFH_27A MC_26W
3 Tons
MM_36E MC_36A PFH_37A MC_38W
MM_40C Self-Contained - Chilled Water
Table 2 System configurations - 50Hz
Nominal
Capacity
Cooling
Unit
Condensing Unit
Indoor Air-Cooled
Centrifugal fan
Outdoor Air-Cooled
Propeller Fan
Indoor Remote
Water/Glycol-Cooled
3 Tons
MM_35E MC_35A PFH_36A MC_37W
MM_39C Self-Contained - Chilled Water
Table 3 Application limits, evaporator and chilled water units*
Input Voltage Range of Return Air Conditions to Unit
Minimum Maximum Dry Bulb Temperature Relative Humidity
-5% +10% 65°F to 85°F (18°C to 29°C) 20% to 80%
* Unit will operate at these conditions but will not control to these extremes of conditions.
Table 4 Application limits, indoor and outdoor air-cooled condensing units
Input Voltage
Condensing
Units
Entering Dry Bulb Air Temperature
Minimum Maximum Minimum Maximum
-5% +10%
Outdoor Prop Fan
Condensing Unit
-30°F (-34°C)
115°F (46°C) standard unit*
125°F (52°C) high ambient unit*
Indoor Air-Cooled
Condensing Unit
115°F (46°C)*
* Unit capacity ratings are stated for 95°F (35°C) for standard units and 105°F (41°C) for high ambient PFH units only.
Exceeding these rating points by 20°F (11°C) will result in lower cooling capacities, but will not damage the equipment.
Table 5 Application limits, indoor water/glycol-cooled condensing units
Input Voltage Entering Fluid Temperature
Minimum Maximum Minimum Maximum
-5% +10% 65°F (18.3°C) * 115°F (46°C)
* Operation below 65°F (18°C) may result in reduced valve life and fluid noise.
