Site Preparation and Installation
Liebert
®
Mini-Mate2
™
24
Figure 13 Dimensions, evaporator and chilled water units with direct drive blower
Table 15 Net weights—evaporator and chilled water units
Model #
Weight, lb (kg)60Hz 50Hz
MM*24E — 225 (102)
MM*24K — 245 (111)
MM*36E MM*35E 225 (102)
MM*36K MM*35K 245 (111)
MM*40C MM*39C 230 (104)
Source: DPN000193, Rev. 3
1"
(25.4mm)
11"
(279mm)
20" (508mm)
15"
(381mm)
18"
(457mm)
18"
(457mm)
19-7/8"
(505mm)
Duct
Flange
3/4"
(19mm)
1"
(25.4mm)
Filter Box (optional)
24"
(610mm)
Cabinet
Dimension
18" (457mm)
18"
(457mm)
18" (457mm)
Cabinet Dimension
same as above
Hanging
Bracket
Shaded area
indicates a recommended
clearance of 30" (762mm)
for access and filter removal
Shaded area indicates a
recommended clearance
of 30" (762mm) for access
and filter removal
7/8" (22mm) holes
for module rigging
(typ. 2 each end).
Note: Unit is spaced evenly in
reference to threaded rod centers
1-7/16"
(37mm)
1-7/16"
(37mm)
14"
(356mm)
Removable
Access
Panels
27-13/16"
(706mm)
Threaded Rod
Centers
Cabinet Outline
Removable panel on
side of plenum.
Minimum clearance
30" (762mm) for filter
access and removal
Air Discharge out
sides of plenum
Air Discharge out
sides of plenum
Cover Plate
Supplied With
Plenum
Air Inlet through
grille in center of plenum
24"
(610mm)
Overall
Dimension
Optional Air Distribution Plenum
All piping and electrical field connections are the same
30"
(762mm)
Cabinet
Dimension
DPN000193
Rev. 3
6" (152mm)
48"
(1219mm)
Overall
Dimension
3-7/8"
(98mm)
14"
(356mm)
14"
(356mm)
Customer-Supplied
Threaded Rods for
Module Suport from
Ceiling (Typ. 4)
11-1/8"
(283mm)
5"
(127mm)
3-1/4"
(83mm)
Overall
Dimension
Dimension
55-13/16"
(1418mm)
Rod
Centers
57-13/16"
(1468mm)
54"
(1372mm)
Optional discharge air
duct flange supplied when
optional filter box is ordered
10-7/8"
(276mm)
11-5/8"
(295mm)
Cabinet
Threaded
Module Dimensions
