Table 25 Equipment switch settings (unit control board)
Switch OFF Position ON Position
1 Compressor Chill Water
2 Staged Reheat SCR Reheat
3 Not Used--Must remain in OFF position
4 Not Used--Must remain in OFF position
5 Enable Reheat Disable Reheat
6 Enable Humidifier Disable Humidifier
7 Enable Dehumidifier Disable Dehumidifier
8 Electric Reheat Gas Reheat
Table 26 Switch settings (wall box board)
Switch OFF Position ON Position
1 Disable Beeper Enable Beeper
2 Not Used--Must remain in OFF position
3 Not Used--Must remain in OFF position
4 Not Used--Must remain in OFF position
5 Not Used--Must remain in OFF position
6
Compressor on continuously
for tight control
Economy Mode
7 Disable Setback Enable Setback
8 Enable Password Disable Password
