HDMI-TPS-RX110AY – User's Manual 34
Create and Restore Backups from the Device Memory
HDMI-TPS-RX110AY receiver is able to store backups in its own memory and can be recalled from there so
You can save presets as not protected with using Save button and as protected with using the Save as protected
button. Restoring a preset select on the slot of the desired backup and click on the Apply button. You can
Upload button and you can also save a
Download button. If you do not need a saved
preset any more, select it and click on the Delete button.
WARNING! Loading factory default settings will erase all presets which has been saved in the device
memory!
Advanced View Window
4
5
7
1
LW3 protocol help Pushing the button results a help window opening which describes the most
2
Edit mode The default appearance is the read-only mode. If you want to modify the
selection.
3
Warning mode If this pipe checked in, a warning window pops up when you enable Edit mode.
4
Terminal window Commands and responses with time and date are listed in this window. Sent
The color of each item depends on the type of the command and response.
The content of the window can be emptied by the Clear button. If the Autoscroll
option is ticked, the list is scrolled automatically when a new line is added.
5
Command line Type the desired command and execute it by the Send button. Clear all current
commands and responses in the Terminal window by the Clear button.
6
Protocol tree
7
Node list Correspondent parameters and nodes are shown which are connected to the
selected item in the protocol tree.
Manual button: Manual (short description) of the node can be called and
displayed in the terminal window.
Set button:
Call button: Calls the method, e.g. reloads factory default settings.
