HDMI-TPS-RX110AY – User's Manual 52
non-HDCP compliant display. See more information in the HDCP Management section.
Command format: SET●
n
Response format: pw●
n
Example:
˃ SET /MEDIA/VIDEO/I1.HdcpEnable=false
˂ pw /MEDIA/VIDEO/I1.HdcpEnable=false
transmitted to a non-HDCP compliant display. See more information in the HDCP Management section.
Command format: SET●
n
Response format: pw●
n
Parameters:
.HdcpModeSetting 0 1
HDCP mode Auto Always
Example:
˃ SET /MEDIA/VIDEO/O1.HdcpModeSetting=0
˂ pw /MEDIA/VIDEO/O1.HdcpModeSetting=0
Test Pattern Generator
The output ports can send a special image towards the sink devices for testing purposes. The setting is
available on output ports with the below-listed parameters.
Test Pattern Generator Mode Setting:
Command format: SET●
n
Response format: pw●
n
Parameters:
.TpgMode 0 1 2
Test pattern generator
mode
Disabled
The test pattern is not
displayed on the output
Enabled
The test pattern is
displayed on the output
No signal mode
The test pattern is
displayed if there is no
signal on the output port
Example:
˃ SET /MEDIA/VIDEO/O1.TpgMode=2
˂ pw /MEDIA/VIDEO/O1.TpgMode=2
Command format: SET●
n
Response format: pw●
n
Parameters:
.TpgClockSource 480 576 EXT
Clock frequency 480p 576p External clock (from actual TMDS source)
Example:
˃ SET /MEDIA/VIDEO/O1.TpgClockSource=576
˂ pw /MEDIA/VIDEO/O1.TpgClockSource=576
