Linde 1202 Series - Overhead Switches

Overhead Switches
1
3
5 7 9 11 13 14 16 18
2
4 6 8 10 12
15 17
d12020003
Push button for windscreen wiper func-
tions− roof panel wiper can be switched on
Push button for windscreen wiper func-
tions− speed levels
Push button for working spotlights, positions
5/6
Push button for front only or front/rear LED
light stripes
Push button for work lights, positions 3/4
Push button for work lights, positions 1/2
Push button for work lights, positions 7/8
Push button for rear LED light stripes
1
2
3
4
5
6
7
8
Push button for floor spot lights
Not used
Push button for road lights
Push button for parkign lights (lighting when
the truck is switched off)
Switch for hazard warning lights
Push button (F1) for optional equipment
Push button (F2) for optional equipment
Push button (F3) for optional equipment
Push button (F4) for optional equipment
Switch for optional equipment
9
10
11
12
13
14
15
16
17
18
Overview
3
Overhead Switches
