Seat Belt
WARNING
Failure to properly wear the seat belt can result in
death or serious injury in the event of an accident.
Always wear the seat belt when operating the truck.
WARNING
A malfunctioning or damaged seat belt can result in
death or serious injury in the event of an accident.
Ensure that the belt always operates correctly. It
must not become twisted, trapped or tangled up. The
catch and belt retractor must be protected from dirt,
damage, or foreign objects. A damaged or frayed
seat belt must be repaired or replaced before operat-
ing the truck.
The automatic locking mechanism will prevent
the belt from being pulled out of the retractor
whenever the truck is on a steep slope. To re-
lease the locking mechanism, carefully move
the truck so that it is no longer positioned at
an angle.
While using the vehicle (e.g. driving, operat-
ing lift mast etc.), adopt a sitting position as
far back as possible so that the driver's back
rests against the seat back. The automatic
locking mechanism of the belt retractor offers
sufficient freedom of movement on the seat for
normal use of the fork-lift truck.
Buckle monitoring
The truck controller monitors the status of the
buckle as well as the sequence in which it
is fastened at start-up. If the truck is driven
without the seat belt fastened, a tone sounds
at speeds above 2.5 mph (4 km/hr). The truck
may be further configured with a speed re-
striction (all the way to zero) if the seat belt
is not fastened in the proper sequence. To
satisfy the sequence requirement, the seat
switch must be activated (driver seated) and
the electrical system switched on before the
seat belt is fastened. Otherwise the truck will
be restricted to the programmed speed.
3 2
4
1
5
d12020019a
6
Display_1074a
4
Operation
Operator Compartment
66 Operating Instructions-1202 series LP 12028011590US-11/2022 - 04
