Linde 1202 Series - Armrest Adjustment

Armrest Adjustment
 Occupy the driver's seat and loosen the
clamping screw (1).
 Move the armrest console (2) up-
wards/downwards and forwards/backwards
until the arm rest pad (3) is comfortably
positioned and the hydraulic control levers
can be easily reached.
 Tighten the clamping screw (1).
2
3
1
1202 08102020-01

Operation
4
Operator Compartment
65Operating Instructions-1202 series LP 12028011590US-11/2022 - 04
