Linde 1202 Series - Steering Column Adjustment

Steering Column Adjustment
WARNING
Driving with the tilt angle locking knob loose can
cause a collision due to loss of control.
Adjust the steering column tilt angle only when the
vehicle is stationary.
The angle of the steering column can be ad-
justed to suit the operator. In addition, a height
adjustment is available as an option. Both ad-
justments are made with the locking knob (2).
 Loosen the locking knob (2) by turning it
counter-clockwise.
 Push the steering wheel (1) forward or pull
it back into the desired position.
 If the truck is equipped with the option-
al height adjustment, pull upward or push
downward axially on the steering wheel until
the desired height is reached.
 Tighten the locking knob by turning it clock-
wise.
1
2
d12020047

Operation
4
Operator Compartment
69Operating Instructions-1202 series LP 12028011590US-11/2022 - 04
