Use the , , and push buttons
to select the required displays, settings or
malfunctions and information.
1 Status display menu (e.g. time/date, steering angle)
2 Favorites display menu (e.g. tilt angle)
3 Settings menu (e.g. language, units, date format/hour format, date)
4 Malfunctions and information menu (e.g. error code, messages, QR code, status icons)
NOTE
The
Status display
and the
Favorites display
save the last displayed view and display this
view again after the electrical system has
been switched back on.
NOTE
The
"Malfunctions and information"
symbol is
displayed in the following colors depending on
the status of the truck:
●
"
Yellow
" means: malfunction or information
●
"
Red
" means: critical malfunction or infor-
mation
●
"
+
" on the symbol means: multiple malfunc-
tions or items of information
NOTE
If there are no malfunctions or items of infor-
mation, the respective "Error code", "Messag-
es" and "Status icons" (displayed only if more
than six status icons are active) menu items
are hidden.
Overview
3
Menu Structure, Standard Display Unit
35Operating Instructions-1202 series LP 12028011590US-11/2022 - 04
