Linde 1202 Series - Page 71

 Move the lever (3) upwards for a heavier
weight.
 Move the lever (3) downwards for a lighter
weight.
Lumbar Adjustment (optional equip-
ment)
NOTE
The lumbar support enables the seat backrest
contour to be optimally adapted to the driver's
body.
 Turn the knob (5) to the left or right.
The extent to which the lower and upper areas
of the backrest are curved is adjusted individu-
ally.
Seat Heating (optional equipment)
 Push the switch (6) upwards to activate the
seat heater.
 Push the switch (6) downwards to deacti-
vate the seat heater.
NOTE
The maximum temperature is predefined.
6
5
d12020012a

6
5
d12020012a

Operation
4
Operator Compartment
61Operating Instructions-1202 series LP 12028011590US-11/2022 - 04
