Linde E30 - Traction Enable from Series 7;95

Service Training
Section 2.6
Page 39
2.6.6.2.2 TRACTION ENABLE FROM SERIES 7/95
Battery negative is applied to the traction module 1X13:21 via seat switch 1S50 and overhead guard switch
9S20.
When seat switch 1S50 or overhead guard switch 9S20 is opened, the timer relay opens after a delay of
approx. 2 seconds in order to prevent inappropriate switching when travelling on an uneven roadway.
