Wall-Mounting Placement
The router has wall-mount slots on the bottom of each foot for flexibility in mounting
the router on the wall. The distance between the slots on the short side is 05 mm.
The distance between the slots on the longer side is 2 mm. Two screws are needed
to mount the router.
Suggested Mounting Hardware
3 mm
6-7 mm 1.5-2 mm
Note:
Linksys is not responsible for damages incurred by unsecured wall-mounting
hardware.
Mounting Instructions
 Determine where you want to mount the router and which side you should use to
mount it. Make sure that the wall you use is smooth, flat, dry, and sturdy. Make sure
the location is within reach of an electrical outlet.
• Beforedrillingholes,choosethetemplate(shortsideorlongside)thatfitsyour
installation. Drill the holes using the correct template.
• Insertascrewintoeachholeandleave8mmofitsheadexposed.
• Positiontheroutersothewall-mountslotslineupwiththetwoscrews.
•. Placethewall-mountslotsoverthescrewsandslidetherouterdownuntilthe
screws fit snugly into the wall-mount slots.
Wall-Mounting Template (Short Side)
Print this page at 00% size.
Cut along the dotted line, and place on the wall to ensure precise spacing of holes.
