Rev: 06.14.2016
Page 22
IN-WALL® Slide-out Service Manual
Upper Gear
Rack
Lower Gear
Rack
H-Column
IN-WALL
®
SLIDE-OUT ASSEMBLY
SLIDEOUTS
Upper Bearing Block Detail
Lower Bearing Block Detail
Gear Rack
Torque Shaft
Lower Bearing Block
Spur Gear
V-Roller
Shoe
Gib
Motor
Shoe
V-Roller
Upper Bearing Block
Gear Rack
Gib
Torque
Shaft
