CHAPTER 1: ALARMS 1-26
Bar Feeder Software Sequence of Events
Sequence no. Movement
0 Stop mode and manual functions
1 Production cycle.
2 Loading start. The pusher returns back to home position.
3 Diameter selection start.
4 The loading table starts moving up
5 The loading flag moves to the bar stock rear.
6 The loading flag pushes the bar stock under the measuring cell SQ3
7 Calculation
8 The loading flag pushes the bar stock behind the clamping device.
9 The loading flag pushes the bar stock to the EOB or to the top cut position.
10 Production cycle with loading table in upper position.
11 The loading flag moves back to home position.
12 The loading table starts moving down.
13 The pusher moves to the bar stock rear.
14 The pusher moves the bar stock behind the clamping device.
15 The pusher positions the bar stock in top cut position
16 In top cut position.
QUICK LOAD SERVO 65/80
