3- CHAPTER 3: PROCEDURES
3-6
Pusher Changeover Procedure
Conditions:
- Bar feed power on.
- Loading table in lower position.
- Pusher at the mechanical home position.
- Bar feed in STOP mode.
Procedure:
Step 1: Open the main access cover.
Step 2: Pull the carrier away from the home position.
Step 3: Press the pusher adapter locking/unlocking finger toward the front of the bar feeder, then turn the finger a
¼ of a turn clockwise. The finger must stay locked in forward position. Pull the pusher towards the bar
feeder front but don't extract it completely out of the carrier.
QUICK LOAD SERVO 65/80
