CHAPTER 1: ALARMS 1-6
A04 – Bar feeder retracted or not locked in its working position
BAR FEEDER
RETRACTED OR
NOT LOCKED IN ITS
WORKING POSITION!
A04
SQ12
Description:
The « bar feeder retracted or not locked in its working position » alarm occurs whenever the PLC does
not detect input (I19 – SQ12). The problem is generated when the bar feeder is retracted in reduction
tube change position or if the retraction system is not locked.
Solution:
In the working screen, press the
key on the remote control. Press the key corresponding to Page
Down until the INPUTS page is displayed:
Case Input Solution
1 SQ12 = 0 Set the bar feeder back in operating position and lock it.
2 SQ12 = 1 Press the STOP button on the remote control to reset the alarm.
QUICK LOAD SERVO 65/80
