24 Output/Input Connections
Transducer 1
1. NC.
2. Auxillary analog input. (LX400)
3. Transducer 1 current input.
4. +10 volt excitation.
5. Auxillary analog input. (LX400)
6. Shield.
7. Ground.
Transducer 2
1. NC.
2. Auxillary analog input.
3. Transducer 2 current input.
4. +10 volt excitation.
5. Auxillary analog input.
6. Shield.
7. Ground.
Power/Control (15 way)
1. -VE SUPPLY
2. +VE SUPPLY
3. INTERLOCK
4. REMOTE ADD
5. AUXILLARY ANALOG 2
6. TRIGGER 1
7. AUXILLARY ANALOG 1
8. AUX INPUT
9. AUXILLARY INDICATOR
10. TRIGGER 2
11. AUX OUTPUT
12. NC.
13. NC.
14. +VE SWITCHED OUTPUT
15. -VE SWITCHED OUTPUT
