2 The Loadrite LR810 Weighing System
The Loadrite LR810 weighing system measures the weight of loads lifted by
front end loaders, log loaders, fork lift trucks and similar machines which
use hydraulic rams to lift the load.
The heart of the system is the LR810 indicator which provides a keypad for
entering instructions and LCD screens to display readings and messages.
The indicator has internal memory which stores settings and production data
even when switched off.
The LR810 is installed in the cab of the loading machine and is connected to
sensors on the lifting arms.
Main Parts of the LR810 System
The main parts of the controller are shown in the diagram below.
