Technical data
Jack 3.5 mm: ......................................................... Headphones 32- 2000 ohm
Mini-DIN (AVS) Video IN:..............................................................Y/C (S-VHS/Hi 8)
............................................................CVBS (VHS/8 mm)
Cinch (yellow) Video IN:...........................................................CVBS (VHS/8 mm)
Cinch (white/red) Audio IN: ............................................................L (white) / R (red)
2x IEC socket 75 Ohm/5 V/80 mA: ................................ Antenna/cable/DVB-T/C
2x F socket 75 Ohm 13/18 V/350 mA: ..............................ANT-SAT DVB-S/S2
Jack 3.5 mm AUDIO IN2: ..............................................................................L/R
Cinch AUDIO IN max. 2Vrms:.......................................................Centre
2 x Cinch AUDIO IN1: ........................................................L (white) / R (red)
2 x Cinch AUDIO OUT (level depends on configuration): ...L (white) / R (red)
Cinch COMPONENT IN: .......................................................Cb/Pb signal
Cinch COMPONENT IN: .........................................................Cr/Pr signal
Cinch COMPONENT IN: .............................................................. Y signal
Cinch AUDIO DIGITAL IN (SPDIF): ........................................Digital audio
Cinch AUDIO DIGITAL OUT (SPDIF): ....................................Digital audio
SUB-D AUDIO LINK: .............................................................. Multi-sound
SUB-D PC IN:..............................................................PC/STB video signal
SUB-D RS-232C: ................................................................serial interface
Mini-DIN SERVICE: .................................................................. Service/L-Link
Mini-DIN CONTROL: ...... Rotating stand control (Positioning accuracy 1.5°)
Jack 3.5 mm IR-Link: .......................................... Output for infrared transmitter
2 x USB USB 2.0: ........................................MP3/WMA/Standard JPEG files
2 x HDMI Digital Video/Audio IN
Type A 19pole Standard 1.3: ....................Digital video and audio
2 x CI-Slot Common Interface ......................................... Slot for CA module
Ethernet (8P8C) LAN:..................................................................Network interface
Electrical data
Chassis designation: ........................................................................................... L 2715
Power supply: ........................................................................220 V – 240 V/50–60 Hz
Tuner: .................................................................................. VHF/UHF/cable/hyperband
Range:.......................................................................................... 45 MHz to 860 MHz
Station storage locations incl. AV and radio: ......................................................... 4000
TV standards: .................................................................................. B/G, I, L, D/K, M, N
Colour standard: ....................................... SECAM, PAL, NTSC, NTSC-V, PAL-V (60 Hz)
Sound standard .....................................................Mono/Stereo/2-Ton/Nicam B/G, I, L
.............................................Dolby Digital, Dolby Virtual Speaker, DTS
Audio output power (music/sine): ................................................4 x 40 W / 4 x 20 W
Teletext: .......................................................................................... TOP/FLOF Level 2.5
Page memory ........................................................................................................ 2000
Digital teletext (only in UK / IRL with active MHEG-5 software) .......................MHEG-5
Connections
Mains socket: ..................................................................................... Supply voltage
EURO-AV 1 Video IN: ....................................................................Y/C (S-VHS/Hi 8)
.................................................................CVBS (VHS/8 mm)
Video OUT: .............................................................CVBS (VHS/8 mm)
................................................................Y/C (S-VHS/Hi 8)
Audio IN: ........................................................................................L/R
Audio OUT: .....................................................................................L/R
EURO-AV 2 Video IN: ....................................................................Y/C (S-VHS/Hi 8)
.................................................................CVBS (VHS/8 mm)
.......................................................................................RGB
Video OUT: .............................................................CVBS (VHS/8 mm)
......................................... Y/C, (only with SVHS Link Plus)
Audio IN: ........................................................................................L/R
Audio OUT: .....................................................................................L/R
General data
Type Reference 52
Article number 68426xxx
Device dimensions without stand (W x H x D) in cm
Device dimensions with stand (Floor Panel Reference) (W x H x D) in cm
129,5 x 107,2 x 6,7
129,5 x 120,1 x 40,0
Weight for device without stand (approx.) in kg
Weight for device with stand (Floor Panel Reference) (approx.) in kg
58,6
83,9
Display technology Full-HD 200Hz LCD technology
Picture diagonal (in cm) / picture format 132 / 16:9
Resolution (in pixels) / Frame rate 1920 x 1080 / 200Hz
Contrast ratio (static / dynamic) 5.000:1 / 30.000:1
Viewing angle (horizontal/vertical) 178° / 178°
Power consumption (EN 62087:2009)
Power consumption "On" (W)
Power consumption in standby mode (W)
Power consumption when the set is turned off (W)
250
0,7
0
Ambient temperature (Celsius) 5° – 35°
Relative humidity (non-condensing) 20 – 80%
Air pressure 800 – 1114 hPa (0 – 2000 m above sea level)
