MAINTENANCE MANUAL OF ENGINE
101
4.2 Installing the gear chamber
1. Install the crankshaft (For details see Section 4.2,
Chapter 2 of this Part).
2. Install the idler shaft A.
A-Idler shaft
3. Install the gasket A.
A-Gear chamber gasket
Attention
During installation, replace it with a new one.
4. Install the gear chamber A, and install and tighten
the set bolt B.
A-Gear chamber
B-Bolt
A
A
B
A
