1. Basic information & precautions
1-2
SV-iC5
1.2 Product Details
1.2.1 Appearance
1.2.2 View without the front cover
Refer to Page 1-3 for front cover removal.
Front Cover:
Remove it when
wiring and changing
parameter setting.
Bottom Cover:
Remove it when
wiring input power
and motor.
Status LED
Display Window
Inverter Nameplate
4-Way button for
parameter setting
(Up/Down/Left/Right key)
Analog
Input/Output
Terminal
NPN/PNP
Select Switch
Keypad
Potentiometer
STOP/RST
Button
RUN Button
Inverter Ground Terminal
☞ Caution: Remove the
bottom cover to access
the terminal.
Body slot: When front
cover is pulled back till
this line and lifted up, it
can be removed from
main body. See Page 1-3
