11. Monitoring
11-2
SV-iC5
User display select
Group LED Display
Parameter Name
Set
value
Min/Max
range
Factory
default
Unit
Drive group
vOL
[User display select]
-
Function
group 2
H73 [Monitoring item select] - 0/2 0
The selected item in H73- [Monitoring item select] can be monitored in vOL- [User display select].
H73 : Select one of the desired item numbers.
H73 [Monitoring item
select]
0 Output voltage [V]
1 Output power [kW]
2 Torque
Enter motor efficiency indicated on motor nameplate to H36 to display correct torque
Power on display
Group
LED
display
Parameter Name Setting
Factory
default
Function
group 2
H72
[Power on display]
0
Frequency command (0.0)
0
`
1 Accel time (ACC)
2 Decel time (DEC)
3 Drive mode (drv)
4
Frequency mode (Frq)
5 Multi-step frequency 1
6 Multi-step frequency 2
7 Multi-step frequency 3
8 Output current (CUr)
9 Motor rpm (rPM)
10
Inverter DC link voltage (dCL)
11
User display select (vOL)
12
Fault display 1
13
Fault display 2
Select the parameter to be displayed on the keypad when the input power is first applied.
