LS Industrial Systems SV-iE5 Series User Manual

Chapter 7. Function List
7-11
Display Name
Min/Max
range
Description
Factory
defaults
Adj.
during
run
P66
Multi-function
input terminal
P1 define
0 ~ 24
0 Forward run command (FX)
0 O
1 Reverse run command (RX)
P67
Multi-function
input terminal
P2 define
2
EST-
Emergency Stop Trip :
temporary output cut-off
1 O
P68
Multi-function
input terminal
P3 define
3 Reset when a fault occurs(RST)
2 O
4 Jog operation command (JOG)
P69
Multi-function
input terminal
P4 define
5
Multi-Step freq – low
3 O
6 Multi-Step freq – high
P70
Multi-function
input terminal
P5 define
7 -
4 O
8
-
9 -
10
-
11 DC brake during stop
12
-
13 -
14
-
15
Up-
down
Frequency up
16
Frequency down
17 3-wire operation
18
External trip: A Contact (EtA)
19 External trip: B Contact (EtB)
20
Change from PI operation to
general operation
21 -
22
Analog Hold
23 Accel/Decel Disable
24
Up/Down Save Freq. Initialization
P71
Input
terminal
status
display
-
BIT4 BIT3 BIT2 BIT1 BIT0
- -
P5 P4 P3 P2 P1
