LS Industrial Systems SV-iE5 Series User Manual

Chapter 7. Function List
7-12
Display Name
Min/Max
range
Description
Factory
defaults
Adj.
during
run
P72
Filtering time
constant for
Multi-function
Input terminal
1 ~ 20
If the value is set higher, the
responsiveness of the Input terminal is
getting slower.
3 O
P73
Analog output
item select
0 ~ 3
Output item
Output to 10[V]
0 O
0
Output freq.
Max frequency
1
Output current
150 %
2
Output voltage
282 V
3
Inverter DC link
voltage
DC 400V
P74
Analog output
level
adjustment
10 ~
200
[%]
Based on 10V. 100 O
P75
Frequency
detection level
0 ~ 200
[Hz]
Used when P77 is set to 0-4.
Cannot be set higher than P16.
30.00 O
P76
Frequency
detection
bandwidth
10.00 O
P77
Multi-function
relay select
0 ~ 17
0 FDT-1
17 O
1 FDT-2
2 FDT-3
3 FDT-4
4 FDT-5
5 -
6 Inverter Overload (IOLt)
7 Motor stall (STALL)
8 Over voltage trip (OVt)
9 Low voltage trip (LVt)
10 Inverter cooling pin Overheat (OHt)
11 Command loss
12 During Run
13 During Stop
14 During constant run
15
During speed searching
16
Wait time for run signal input
17
Fault output select
