LS tractor MT125 User Manual

Contents
3. Instruments and Controls
3-1. Instrument panel and Front controls
(1) Instrument panel ········································3-2
(2)Keyswitch············································3-4
(3)Turnsignallightswitch····································3-4
(4)Lightswitch············································3-5
(5)Hazardwarninglightswitch································3-5
(6)PTOswitch ········································3-6
(7) Brake pedal ······································
···3-7
(8)Parkingbrakelever····································
· ·3-7
(9)Throttlelever··········································3-8
(10) HST forward / reverse pedal (HST type) · · · · · · · · · · · · · · · · · · · · · · 3-8
(11)Cruisecontrolswitch(HSTtype)····························3-9
3-2. Left / Right-hand side Levers and Pedals
(1) Range gear shift lever····································3-11
(2)4WDlever····································3-11
(3)Worklightswitch···································3-12
(4)PTOselectlever·······································3-12
(5)Electricalpoweroutletsocket······························3-13
(6) Differential lock pedal· · · · ·································3-13
3-3. Hydraulic System
(1)Safetyprecautions···································
· ··3-14
(2)Steeringsystem·····································
· · · 3-15
(3)HydraulicliftControl··································
· · · 3-16
(4)Midmowerheightadjustmentknob·························3-17
(5)RemotecontrolleverandQuickcoupler(optional)···············3-18
(6)Joysticklever(iffitted)··································3-19
(7)HydraulicSystemDiagram ································3-20
4. Operation and Work
4-1. Engine start and stop
(1)Enginestart············································4-1
(2)Startincoldweather·····································4-3
(3)Enginestop············································4-3
4-2. How to drive and stop
(1)Howtodrive ·········································· 4-4
(2) Changing speed ········································4-6
(3)EmergencyStop········································4-7

LS tractor MT125 Specifications

General

Engine Power	24.7 HP
Transmission	Hydrostatic
Drive	4WD
Transmission Speeds	Infinite (2-range)
PTO Speed	540 RPM
Hydraulic System	Open center
3-Point Hitch	Category I
Tire Size (Front)	18x8.5-10
Tire Size (Rear)	26x12-12
Engine Type	Diesel
Fuel Capacity	6.6 gal
