3 -13
(6) Differential lock pedal
z If the tractor cannot go forward as one side rear
wheels are slipping, depress the clutch pedal
then press the differential lock pedal.
z Differential lock is effective for working on
slippery ground.
z If engaged, both rear wheels will rotate at equal
speed. So, It disturbs steering operation and you
cannot turn.
▶ Do not turn the tractor while the differential lock is engaged.
▶ Do not use the differential lock while driving on the road.
▶ Stop or drive slow the tractor before engaging the differential lock.
Warning
z Take your foot off the pedal to release the
differential lock. If the traction gap of the rear
wheels is reduced almost, the differential lock is
released automatically.
z If the differential lock does not disengaged
automatically, depress one-side brake pedal (if
fitted) slightly for a second, and/or turn the
steering wheel left and right after stopping
tractor .
Differential lock pedal
Differential lock
(5) Electrical power outlet socket
Electric power
outlet socket
z This is used to withdraw the electric power for
charging of the cigarette lighter jack or cellular
phone.
z In case of using cigarette lighter jack (optional)
-If you push the cigarette lighter jack, the heating
coil generates heat and shall be used as
alternative of lighter.
z In case of using as power supply (12V)
-Use the cellular phone charger less 10A.
Caution
▶ When using a cigarette lighter jack, cares must be taken not to touch the heating
coil. The heat generated coil is very hot and may cause the danger of a burn.
