2 -1
2. Instruction for Safe Operation
(1) The name of each part
HST type
Rear tire
Hood
(Bonnet)
Fender
Instrument panel
Steering wheel
Driver’s seat
Safety frame
(Roll-bar)
Head lights
Front tire
Step
Engine frame
3-point linkage

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the LS tractor MT125 and is the answer not in the manual?

LS tractor MT125 Specifications

General IconGeneral
Engine Power24.7 HP
TransmissionHydrostatic
Drive4WD
Transmission SpeedsInfinite (2-range)
PTO Speed540 RPM
Hydraulic SystemOpen center
3-Point HitchCategory I
Tire Size (Front)18x8.5-10
Tire Size (Rear)26x12-12
Engine TypeDiesel
Fuel Capacity6.6 gal
