3 -12
(4) PTO select lever
z It is used to select the Middle PTO and/or REAR
PTO. If placing the lever as below;
REAR : Rear PTO shall only rotate.
MID+REAR : Middle PTO and rear PTO shaft
shall rotate together.
MID : Middle PTO shaft shall only rotate.
z For PTO shaft speed, refer to the section 6,
“Dimension and specification” in this manual.
z Before starting engine, place the PTO select
lever on “REAR” position. If the lever is placed
on the other position, you can not start the
engine, due to safety interlock system.
▶ After placing PTO switch in OFF and PTO shaft has been stopped completely, shift
the PTO select lever.
▶ If the PTO select lever is NOT engaged smoothly, lift up and down the rear
implement to align the drive shaft.
Caution
(3) Work light (optional)
z There is a switch to turn on the rear work light.
z ON - place the switch to the right direction and
the work light shall be ON.
z OFF - place the switch to the left direction and
the work light shall be OFF.
▶When driving on the road at night, do not let the rear work light stay ON position. It
may cause a disturbance to the driver of the following car.
Caution
OFF
ON
MID
REAR
MID+REAR
PTO select lever
