• 2 banks of 9 pages of Non volatile memory.
• Separate In (up) and Out (down) fade times (0 to 999 seconds).
• Extensive Recording and Editing facilities for Scenes, Chases and Stacks.
• Scene Fade Times can be derived from the Time Faders or from Memory.
• Dedicated Stack Playback module.
• Electronic labelling of all scenes, chases, stacks and stack steps.
• Fully proportional Softpatch.
• Flash level control, with associated Add or Solo mode button.
• Page freeze retains active output when pages or modes are changed.
• User prompts are scrolled on the display and active buttons flash to make operations simple.
• Different languages are available.
• Multi display SVGA colour video output (optional on S and M models).
• DMX 512/1990 output signal. 2 Universes on larger models.
• Power supply is auto selecting, 90−260 volts.
1.3 SPECIFICATIONS
S M L XL XXL
DMX512 Output Channels
512 512 1024 1024 1024
Fader Channels (Wide Mode)
24 48 72 96 120
Fader Channels (Preset Mode)
12 24 36 48 60
Red Playbacks (Scene Mode)
12 24 36 48 60
Pages of Red memory
9 9 9 9 9
Blue Playbacks
N/A N/A 6 18 30
Pages of Blue memory
N/A N/A 9 9 9
Grab Master
1 1 N/A N/A N/A
Maximum number of Scenes *
108 216 378 594 810
Maximum Fade times
>16min >16min >16min >16min >16min
Maximum number of Chases*
108 216 378 594 810
Steps per chase
250 250 250 250 250
Chase speed (Beats Per Minute)
0-999 0-999 0-999 0-999 0-999
Maximum number of Stacks *
13 25 36 48 60
Steps per Stack*
500 500 500 500 500
SVGA Colour Video output
Optional Optional Standard Standard Standard
PATPAD Moving light module
N/A N/A Optional Optional Optional
3.5” Floppy Disk
Optional Optional Standard Standard Standard
Dimensions Height(mm)
155 155 200 200 200
Width (mm)
464 710 831 1047 1264
Depth (mm)
380 380 520 520 520
Weight – packed (kgs)
9.0 13.0 26.0 32.0 38.0
*Subject to memory availability and whether memory Expansion Module is fitted.
1.4 OPTIONS
• MAXLITE 12” Gooseneck desk light (2 required for L, XL & XXL maXims) .
• MAX/V Video and Disk Drive add-on pack for maXim S and M models.
• MAX/P PATPAD moving light module. Not available for maXim S and M models.
• MAX/M Memory Expansion Module.
• Dustcover Sizes available for all models.
• Flightcase Custom flightcases for all models are available to house the maXim, 12V
gooseneck lamps, manual, power lead and floppy disks.
1.5 CARING FOR YOUR MAXIM
The maXim is manufactured from quality components and will give many years of service if you
take some basic precautions.
