maXim Operator Manual Layout
LSC Lighting Systems (Aust) Pty. Ltd. Page 7 of 66
The front panel of the maXim can be divided into two areas;
• Faders and mastering.
• Recording and editing.
Many of the buttons listed below perform more than one function. The current function depends
upon what the operator is doing at the time. Each of these different functions is described under the
relevant button below.
3.1 FADERS AND MASTERS
1. Yellow Bank Faders
Control the levels of channels 1 to 12 (24, 36, 48, 60) respectively.
2. Yellow Bank Master
• Controls the overall level of the Yellow bank faders.
• In WIDE mode, it controls the overall level of the single wide preset consisting of the Yellow bank
faders and the Red bank faders.
3. Mode Red Bank button
Selects the current function for the RED bank faders. The choices are;
• preset.
• wide.
• scene (playback).
4. Red Bank Faders
The Red bank of faders has different functions depending upon the current “MODE” as selected by
the mode red bank button.
• PRESET mode. The Red bank of faders control the levels of channels 1 to 12 (24, 36, 48, 60). A
duplicate of the Yellow bank.
• WIDE mode. The Red bank of faders control the levels of channels 13 (25, 37, 49, 61) to 24 (48,
72, 96, 120).
• SCENE mode. The Red bank of faders become PLAYBACKS. Each Playback can control the
level of a recorded Scene or Chase or it may be empty (does nothing). There are 9 pages of
memory for the red playbacks and the function of each playback depends upon the contents of
the currently selected red page. You determine what each red page contains when you record
(or copy) scenes, chases or stacks into them. Although stacks can be recorded on the red bank,
they can only be played back on the stack master.
5. Red Master
• In PRESET mode, it controls the overall level of the Red bank.
• In WIDE mode it has no function.
• In SCENE mode it controls the overall level of the Red playbacks (Scenes or Chases).
6. Blue Playbacks (L,XL & XXL)
The blue bank of faders are dedicated PLAYBACKS. Each Playback can control the level of a
recorded Scene or Chase or it may be empty (does nothing). There are 9 pages of memory for the
blue playbacks and the function of each playback depends upon the contents of the currently
selected blue page. You determine what each blue page contains when you record (or copy)
scenes, chases or stacks into them. Although stacks can be recorded on the blue bank, they can
only be played back on the stack master.
7. Blue Master
It controls the overall level of the Blue playbacks (Scenes or Chases).
8. Flash/Assign [F/A] Buttons
Below each fader in the fader section is a FLASH/ASSIGN button with an integral red indicator LED.
As their name implies, these are multi purpose buttons.
They may be used to:
• FLASH (or bump) the contents of their particular fader, be it a channel, chase or a scene. (See
also FLASH level and ADD/SOLO button below).
