25
Installing the Inverter
Step 2 Ground Connection
Remove the terminal cover(s) and cable guide. Then follow the instructions below to install
the ground connection for the inverter.
1 Locate the ground terminal and connect an appropriately rated ground cable to the
terminals. Refer to 1.5 Cable Selection on page 10 to find the appropriate cable
specification for your installation.
0.75–30 kW (3-Phase)
37–90 kW (3-Phase)
