403
RS-485 Communication Features
• When PowerOn Resume (COM-96) is set to ‗yes‘, value is saved even if the power of the
inverter is disconnected. If PowerOn Resume (COM-96) is set to ‗no‘, value is not saved
when the power of the inverter is disconnected.
• Cannot set the value higher than the maximum frequency (DRV-20). The maximum
frequency can be set by using the keypad. This value can be used when Freq Ref Src
(DRV-07) is set to ‗Int 485‘.
7.5.3.2 Binary Output
The output point map controlling the inverter from the Metasys-N2 master.
No.
Name
Range
Description
BO1
Stop Command
1: Stop
Stop command
BO2
Run Forward
Command
1: Forward Run
Forward run command
BO3
Run Reverse
Command
1: Reverse Run
Reverse run command
BO4
Reset Fault
1: Reset
Fault reset command
BO5
Free-Run Stop
1: Bx
Free-run stop command
7.5.3.3 Analog Input
Metasys-N2 master monitors inverter state.
No.
Name
Unit
Description
AI1
Output Current
Amps
Output current
AI2
Output Frequency
Hz
Output frequency
AI3
Output Speed
RPM
Output speed
AI4
Trip Code
-
Trip code information
(Refer to Common Area parameter address
0h000F)*
AI5
Latch Trip Info1
-
‗Latch‘ type fault trip information 1
(Refer to Common Area parameter address
0h0330)*
